CuNi 70/30 Seamless Tube C71500 ASME SB111 High Corrosion Resistance Copper Nickel Pipe for Oil & Gas Piping
| Place of Origin | Shanghai,China |
|---|---|
| Brand Name | TOBO |
| Certification | ISO/TUV/SGS |
| Model Number | Copper Nickel Tube |
| Minimum Order Quantity | 1PC |
| Price | Negotiable |
| Packaging Details | Standard Shipping Package |
| Delivery Time | 15-30 Workdays |
| Payment Terms | T/T, Western Union |
| Supply Ability | 10Ton/Month |
Product Details
| Product Name | CuNi 70/30 Seamless Tube C71500 ASME SB111 Oil & Gas Piping Anti-Corrosion Pipe | Thermalconductivity | Good Thermal Conductivity, Approximately 30-40 W/m·K |
|---|---|---|---|
| Astm | C70600, C71500 ASTM B111 ASTM B466, B359 | Corrosion Resistance | High |
| Technical | Cold Drawn | Standard | ANSI, DIN, GB, ISO, JIS, Jpi, ASME |
| Thermal Conductivity | High | Corrosionresistance | High Resistance To Seawater And Industrial Corrosion |
| Tubediameterrange | Typically From 6 Mm To 100 Mm | Types | WN SO BL |
| Meltingpoint | Approximately 1170°C | Technics | Welding |
| Material | Copper Nickel | Materialcomposition | Copper-Nickel Alloy (typically 90/10 Or 70/30 Cu/Ni Ratio) |
| Surface | Bright | Standardscompliance | ASTM B111, ASTM B466, ISO 11951 |
| Highlight | CuNi 70/30 seamless tube,C71500 corrosion-resistant pipe,ASME SB111 oil gas piping |
||
Product Description
CuNi 70/30 Seamless Tube C71500 ASME SB111 Oil & Gas Piping Anti-Corrosion Pipe
1.Product Description
-
Copper-nickel alloy tubes, grades: C70600 (90-10, ~10% Ni) and C71500 (70-30, ~30% Ni)
-
Fe and Mn additions enhance corrosion resistance; single-phase FCC structure, no embrittlement risk
-
Available: Seamless (ASTM B466) / Welded (ASTM B467)
-
Clean oxide-free bore, silver-white finish, precision cold-drawn tolerances
2.Product Applications
-
Marine/Offshore: Seawater cooling, firewater, ballast lines
-
Power/Energy: Condensers, feedwater heaters, air-cooler bundles
-
Desalination: MSF/MED heating sections and evaporator tubes
-
Oil & Gas: Platform utility piping, riser sheathing
-
General Industry: Hydraulic tubing, chemical-resistant piping
3.Product Advantages
-
Corrosion: ≤0.025mm/yr in seawater, self-healing film
-
Biofouling resistance: Natural biostatic, cleaning intervals extended >60%
-
Strength/Toughness: Tensile 275~345MPa, Elongation ≥25%
-
Workability: Weldable, bendable, expandable — no SCC risk
-
Longevity: 15~25 years design life, 100% recyclable
4.Key Product Specifications
| Parameter | 90-10 (C70600) | 70-30 (C71500) |
| Nickel Ni (%) | 9.0~11.0 | 29.0~33.0 |
| Iron Fe (%) | 1.0~1.8 | 0.4~1.0 |
| Tensile Strength (MPa) | ≥275 | ≥345 |
| Yield Strength (MPa) | ≥105 | ≥140 |
| Elongation (%) | ≥25 | ≥30 |
| Hardness HV | ≈130 | ≈150 |
| Density (g/cm³) | 8.90 | 8.94 |
| Thermal Conductivity (W/m·K) | ≈50 | ≈29 |
| Max Service Temp (°C) | 250 | 300 |
| OD Range (mm) | Φ6~325 | Φ6~325 |
| WT Range (mm) | 1.0~30.0 | 1.0~30.0 |
| Single Length (m) | ≤16 | ≤16 |
| Delivery Condition | Annealed(O) / Light-drawn(H) | Annealed(O) / Light-drawn(H) |
| Recommended Max Velocity (m/s) | ≤4.5 | ≤5.0 |
| Applicable Standards | ASTM B466/B467/B111; DIN 86019; GB/T 8890 | Same |
FAQ
1. Are you trading company or manufacturer ? We are manufacturer ,You can see the certification.
2.How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ? Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ? Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
