UNS C71500 CuNi 70/30 Butt Weld Elbow, 90° LR Sch 80 ASTM B16.9 Industrial
| Place of Origin | Shanghai,China |
|---|---|
| Brand Name | TOBO |
| Certification | ISO/TUV/SGS |
| Model Number | Copper Nickel Elbow |
| Minimum Order Quantity | 1PC |
| Price | Negotiable |
| Packaging Details | Standard Shipping Package |
| Delivery Time | 15-30 Workdays |
| Payment Terms | T/T, Western Union |
| Supply Ability | 10Ton/Month |
Product Details
| Product Name | UNS C71500 CuNi 70/30 Butt Weld Elbow, 90° LR Sch 80 ASTM B16.9 Industrial | Surface | Smooth |
|---|---|---|---|
| Sizerange | 1/2 Inch To 24 Inches | Certifications | ASME B16.9, ASTM B466, ASTM B467 |
| Productname | Copper Nickel Elbow | Product Type | Copper Nickel Elbow |
| Applications | Marine, Offshore, Chemical Processing, Desalination Plants | Finish | Smooth, Pickled And Passivated |
| Pressure | High Pressure | Size | Customized Size |
| Type | LR Elbow / SR Elbow | Length | Customized |
| Standard | ASME, ANSI, DIN, JIS, Etc. | Application | Marine, Offshore, Shipbuilding |
| Angle | 45 Degrees / 90 Degrees | Customized Support | OEM, ODM, OBM |
| Highlight | CuNi 70/30 butt weld elbow,90° LR copper nickel elbow,ASTM B16.9 industrial elbow |
||
Product Description
UNS C71500 CuNi 70/30 Butt Weld Elbow, 90° LR Sch 80 ASTM B16.9 Industrial
1. Product Description
Copper nickel elbows are pipe fittings manufactured from copper-nickel alloy (CuNi), primarily grades C70600 (90/10 copper nickel) and C71500 (70/30 copper nickel). The products are formed by forging or hot extrusion, followed by solution treatment to achieve a dense microstructure. They offer excellent seawater corrosion resistance, stress corrosion cracking resistance, and anti-marine fouling performance, making them ideal for highly corrosive piping systems.
2.Product Applications
These elbows are widely used in shipbuilding and offshore engineering (seawater cooling, ballast, and firefighting systems), desalination plant water transmission systems, power plant circulating cooling water, petrochemical corrosive media pipelines, as well as heat exchanger and condenser piping.
3.Product Advantages
-
Superior seawater and erosion resistance: Long-term use without pitting corrosion, even in high-velocity flow conditions.
-
Anti-marine fouling: Naturally inhibits attachment of barnacles, mussels, and algae, significantly reducing maintenance and cleaning costs.
-
Simple weldability: No preheating required before welding, and no post-weld heat treatment needed. Welds maintain corrosion resistance comparable to the base metal.
-
High strength and toughness: Tensile strength ≥300 MPa and good elongation, suitable for vibration-prone or dynamically loaded piping systems.
-
Available certifications: Can be supplied with classification society approvals such as ABS, DNV, BV, and CCS upon request.
4.Key Parameters
| Parameter | Value |
| Material Grades | C70600, C71500, BFe10-1-1 |
| Size Range | DN15 ~ DN600 (1/2″ ~ 24″) |
| Angle Options | 45°, 90°, 180° |
| Bend Radius | Long radius 1.5D, Short radius 1.0D |
| Pressure Rating | 150LB, 300LB, 600LB |
| Operating Temperature | -30℃ ~ +280℃ |
| Applicable Standards | ASME B16.9, MSS SP-43, EEMUA 145 |
FAQ
1. Are you trading company or manufacturer ?
We are manufacturer ,You can see the certification.
2. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
