High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
| Place of Origin | Shanghai,China |
|---|---|
| Brand Name | TOBO |
| Certification | ISO/TUV/SGS |
| Model Number | Copper Nickel Elbow |
| Minimum Order Quantity | 1PC |
| Price | Negotiable |
| Packaging Details | Standard Shipping Package |
| Delivery Time | 15-30 Workdays |
| Payment Terms | T/T, Western Union |
| Supply Ability | 10Ton/Month |
Product Details
| Product Name | High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9 | Packing | Standard Seaworthy Package |
|---|---|---|---|
| Temperature | High | Manufacturing Process | Push, Press, Forge, Cast, |
| Surface Finish | Polished | Head Type | Round |
| Standards | ASTM B466, ASTM B111, ASTM B164 | Joiningmethod | Butt Weld Or Socket Weld |
| Wallthickness | Schedule 10, 40, 80 | Temperature Level | High Temperature |
| Pressure | High | Customized | Customized Support |
| Paking | Wooden Case | Size | 3/4 |
| Payment Term | T/T, L/C, Etc. | End Connection | Butt Weld, Socket Weld, Threaded |
| Highlight | High Pressure CuNi 70/30 Elbow,Copper Nickel 45° Induction Bend,ANSI B16.9 Copper Nickel Elbow |
||
Product Description
High Pressure CuNi 70/30 Copper Nickel 45° Elbow, Hot Induction Bend ANSI B16.9
1. Product Description
Copper nickel elbow is manufactured from copper-nickel alloy (CuNi), common grades C70600 (90/10) and C71500 (70/30). It offers excellent seawater corrosion resistance, anti-fouling properties, and good weldability, suitable for corrosive media piping systems.
2.Product Applications
Mainly used in shipbuilding, marine engineering, desalination, power industry, and petrochemical piping systems, especially for seawater, cooling water, and corrosive chemical media.
3.Product Precautions
-
Avoid direct contact with dissimilar metals such as carbon steel to prevent galvanic corrosion
-
Control interpass temperature ≤100℃ during welding, use matching welding wire
-
Store in dry, well-ventilated environment, keep away from acids, alkalis, and acetylene gas
4.Key Parameters
| Parameter | Value |
| Material Grades | C70600 (90/10), C71500 (70/30) |
| Size Range | DN6 ~ DN600 (1/4″ ~ 24″) |
| Angle Options | 45°, 90°, 180° (other angles available) |
| Bend Radius | Long radius R=1.5D, Short radius R=1.0D |
| Pressure Rating | 150LB, 300LB, 600LB / PN10 ~ PN40 |
| Operating Temperature | -29℃ ~ +260℃ |
| Applicable Standards | ASME B16.9, DIN 86090, GB/T 12459 |
FAQ
1. Are you trading company or manufacturer ?
We are manufacturer ,You can see the certification.
2. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
