CuNi 70/30 Copper Nickel Pipe, Seawater Resistant, ASTM B466 C71500 Welded Tube
| Place of Origin | Shanghai,China |
|---|---|
| Brand Name | TOBO |
| Certification | ISO/TUV/SGS |
| Model Number | Copper Nickel Pipe |
| Minimum Order Quantity | 1PC |
| Price | Negotiable |
| Packaging Details | Standard Shipping Package |
| Delivery Time | 15-30 Workdays |
| Payment Terms | T/T, Western Union |
| Supply Ability | 10Ton/Month |
Product Details
| Product Name | CuNi 70/30 Copper Nickel Pipe, Seawater Resistant, ASTM B466 C71500 Welded Tube | Service | OEM&ODM |
|---|---|---|---|
| Weldability | Good | Surface Treatment | Polished |
| Processing Service | Bending, Welding, Punching, Cutting | Heat Treatability | Good |
| Method | Hot Rolled | Form | Pipe |
| Usages | Construction Decoration | Wallthickness | Varies According To Standard (e.g., SCH10, SCH40, SCH80) |
| Face Type | Round | Technics | Casting |
| Delivery | According To Quantity | Usage | Oil Gas Sewage Transport |
| Density | Approximately 8.9 G/cm³ | Temperature Range | Customizable |
Product Description
CuNi 70/30 Copper Nickel Pipe, Seawater Resistant, ASTM B466 C71500 Welded Tube
1.Product Description
Copper nickel pipe is an advanced corrosion-resistant alloy tube manufactured from high-purity electrolytic copper and nickel, with iron and manganese added as strengthening elements. It is produced through vacuum melting, hot extrusion/piercing, multi-pass cold rolling (or drawing), and bright annealing. Main grades are 90/10 CuNi (UNS C70600) and 70/30 CuNi (UNS C71500). Products are supplied in full compliance with ASTM B466/ASME SB466 (seamless) and ASTM B467/ASME SB467 (welded). Certification by major classification societies (DNV, ABS, LR, etc.) is also available upon request.
2.Product Applications
-
Shipbuilding: Seawater cooling systems for main/auxiliary engines, central coolers, fire mains, ballast and bilge piping.
-
Offshore Engineering: Seawater risers, heat exchangers, and process tracer lines on drilling platforms and FPSOs.
-
Power & Desalination: Steam turbine condensers, nuclear power secondary cooling systems, MSF/MED evaporator tube bundles.
-
Petrochemical & Chlor-alkali: Chloride-resistant heat exchangers, brine and chemical transfer lines.
-
Advanced Equipment: Precision hydraulic circuits, steering gear and brake piping systems.
3 . Product Advantages
-
Life-cycle economy: Ultra-low corrosion rates drastically reduce maintenance and tube replacement, offering lower overall costs compared to stainless steel and titanium.
-
Biofouling resistance: Slow release of copper ions forms a biocidal surface layer, ensuring long-term flow efficiency without periodic cleaning.
-
Superior formability: Supplied in annealed (O) or stress-relieved condition, allowing direct 90° cold bending and flaring without intermediate annealing, saving fabrication time.
-
Reliable welded joints: When welded with matching filler metal, the weld zone achieves corrosion resistance equal to the base metal – no post-weld solution treatment required.
-
Weight saving: About 50% lighter than carbon steel with adequate strength, enabling smaller support structures and lighter overall system weight.
4.Key Product Specification
| Parameter Dimension | 90/10 CuNi (C70600) | 70/30 CuNi (C71500) | General Supply Specifications & Standards |
| Main Alloy System | Cu-10Ni-1.4Fe | Cu-30Ni-0.7Fe | — |
| Tensile Strength Rm (MPa) | ≥ 300 | ≥ 350 | — |
| Yield Strength Rp0.2 (MPa) | ≥ 100 | ≥ 120 | — |
| Elongation A (%) | ≥ 30 | ≥ 35 | — |
| Seawater Corrosion Rate (mm/a) | ≤ 0.025 | ≤ 0.020 | — |
| Thermal Conductivity (W/(m·K)) | ~ 50 | ~ 29 | — |
| Max. Continuous Service Temp. (°C) | ~ 200 | ~ 300 | — |
| Outer Diameter (OD) Range | — | — | Seamless: 6.0 ~ 273.0 mm; Welded: ≤ 355.6 mm (special up to 914) |
| Wall Thickness (WT) Range | — | — | 0.8 ~ 20.0 mm (sized to specification) |
| Fixed Lengths | — | — | 3/6/9/12/18 m or custom cut-to-length |
| Delivery Condition | — | — | Soft (O), Half-hard (H02), Hard (H04) optional |
| Applicable Standards | — | — | ASTM B466/B467, ASME SB466/SB467, ASTM B111, BS EN 12449, DNVGL-CG-0187 |
FAQ
1. Are you trading company or manufacturer ? We are manufacturer ,You can see the certification.
2.How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ? Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ? Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
