Eccentric Copper Nickel Reducer Fitting ASME B16.9 Marine Grade for Corrosive Environments

Place of Origin Shanghai,China
Brand Name TOBO
Certification ISO/TUV/SGS
Model Number Copper Nickel Reducer Fitting
Minimum Order Quantity 1PC
Price Negotiable
Packaging Details Standard Shipping Package
Delivery Time 15-30 Workdays
Payment Terms T/T, Western Union
Supply Ability 10Ton/Month
Product Details
Product Name CuNi 90/10 70/30 Eccentric Reducer Fittings ASME B16.9 Class 150 Marine Grade Face Type Straight Reducing Coupling
Pressurerating 150 PSI To 3000 PSI Productname Reducer Fitting
Length 2.5 In Standard ASME B16.9 / MSS SP-43
Type Concentric/ Eccentric Width 1.5 In
Pressure Rating 3000 Psi Corrosion Resistance High
Wallthickness Schedule 10 To Schedule 80 Process Forged / Extruded Brass Body
Product Code RDF-15 Surface Bright,polished
Endpreparation Beveled / Plain Temperature Rating 400°F
Highlight

Eccentric Reducer Fitting

,

ASME B16.9 Copper Nickel Reducer

,

Marine Grade CuNi Reducer

Leave a Message
Product Description

CuNi 90/10 70/30 Eccentric Reducer Fittings ASME B16.9 Class 150 Marine Grade



1.Product Description



The Copper Nickel Reducer Fitting is a tapered transition component designed to connect pipes of differing diameters within piping systems. It is manufactured from high-quality copper-nickel alloys, primarily in grades 90/10 CuNi (UNS C70600, also known as CuNi90/10 or BFe10-1-1) and 70/30 CuNi (UNS C71500, also known as CuNi70/30 or B30). The fitting is available in two configurations: Concentric Reducers (maintaining a common centerline) and Eccentric Reducers (offset centerlines to facilitate drainage or maintain a flat bottom alignment). The products comply with international standards such as ASME B16.9, DIN 86089, EEMUA146, and GB/T 12459, and offer multiple connection types including butt weld, socket weld, threaded, and flanged joints to suit diverse installation scenarios.

2.Product Applications

These fittings are extensively used in civil and industrial piping systems that handle corrosive fluids. Key application sectors include:

  • Marine and offshore engineering (commercial vessels, offshore platforms, coastal construction) for seawater cooling, fire mains, ballast water, and fresh water systems;

  • Desalination plants for seawater intake, pretreatment, and brine discharge lines;

  • Thermal and nuclear power plants (coastal sites) for circulating cooling water, auxiliary cooling, and condenser systems;

  • Petrochemical and fine chemical industries for brine heat exchange, process cooling, and chemical transfer lines;

  • Municipal water supply and wastewater treatment for large‑diameter pipe size transitions;

  • HVAC and refrigeration systems for cooling water loops;

  • Food and pharmaceutical industries, where corrosion resistance and contamination‑free performance are required.

3.Product Advantages

  • Exceptional corrosion resistance – performs excellently in seawater, saline solutions, and various mild acids/alkalis, with a naturally formed protective oxide film that prevents pitting and crevice corrosion over long service.

  • Inherent anti‑biofouling – the alloy naturally resists marine organism and microbial attachment, reducing maintenance intervals.

  • High strength, toughness, and fatigue resistance – withstands water hammer, vibration, and thermal cycling stresses.

  • Excellent weldability – compatible with TIG, MIG, and arc welding; weld joints are dense, corrosion‑resistant, and match the parent metal without requiring special post‑weld heat treatment.

  • Extended service life and cost‑effectiveness – in chloride‑containing and elevated‑temperature environments, service life far exceeds that of carbon steel and ordinary stainless steel, lowering total lifecycle costs.

  • Smooth diameter transition – the tapered geometry minimizes turbulence and pressure drop, enhancing system energy efficiency.

  • Wide applicability – available in multiple pressure ratings (Class 150–900, PN 6–100) and wall thickness schedules to suit diverse operating conditions.

Eccentric Copper Nickel Reducer Fitting ASME B16.9 Marine Grade for Corrosive Environments

​4.Key Product Specifications



Item Specification
Material Grades 90/10 CuNi (UNS C70600 / BFe1011); 70/30 CuNi (UNS C71500 / B30)
Nominal Size Range DN15 ~ DN1200 (1/2″ ~ 48″); commonly DN20~DN500
Types Concentric Reducer; Eccentric Reducer
Connection Types Buttweld (BW), Socketweld (SW), Threaded (THD), Flanged (FL)
Manufacturing Standards ASME B16.9 / B16.28, DIN 86089, EEMUA146, GB/T 12459, MSSSP43
Material Standards ASTM B122 / B171 / B466 / B467; ASME SB466 / SB467
Pressure Ratings ANSI Class 150, 300, 600, 900; DIN PN 6, 10, 16, 25, 40, 64, 100; EU 16Bar, 20Bar
Wall Thickness Schedules SCH 5S, 10S, 10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160, XXS
Chemistry (90/10) Cu ~90%, Ni ~10%, Fe ~1.5%, Mn ≤1%
Chemistry (70/30) Cu ~70%, Ni ~30%, Fe ~0.51%, Mn ≤1%
Tensile Strength 275 ~ 485 MPa (depending on grade and heat treatment)
Quality Certification Compliant with ISO 9001:2015 requirements
