C71500 Copper Nickel Seamless Tubing, Precision for Heat Exchanger
| Place of Origin | Shanghai,China |
|---|---|
| Brand Name | TOBO |
| Certification | ISO/TUV/SGS |
| Model Number | Copper Nickel Pipe |
| Minimum Order Quantity | 1PC |
| Price | Negotiable |
| Packaging Details | Standard Shipping Package |
| Delivery Time | 15-30 Workdays |
| Payment Terms | T/T, Western Union |
| Supply Ability | 10Ton/Month |
Product Details
| Product Name | C71500 Copper Nickel Seamless Tubing, Precision For Heat Exchanger | Usages | Construction Decoration |
|---|---|---|---|
| Yield Strength | High | Connection | Welding |
| Temperature Rating | 400°F | Machinability | Good |
| Joiningmethods | Brazing, Welding, Soldering | Technique | Cold Drawn, Hot Rolled |
| Prodcut | Copper Nickel Pipe | Technics | Casting |
| Diameterrange | 1/2 Inch To 24 Inches | Materialcomposition | Copper-Nickel Alloy (commonly 90/10 Or 70/30 Cu-Ni) |
| Application | Air Condition Or Refrigerator | Size | Customized |
| Wallthickness | Schedule 10 To Schedule 40 | Delivery | According To Quantity |
Product Description
C71500 Copper Nickel Seamless Tubing, Precision for Heat Exchanger
1.Product Introduction
Copper nickel pipe is a high‑performance alloy tube manufactured from Cu‑Ni systems, primarily grades 90/10 (C70600) and 70/30 (C71500), with controlled additions of iron and manganese. Available in seamless and welded forms, it complies with ASTM B466, ASTM B111, ASME SB111, EN 12451 and JIS H3300. It is the preferred material for seawater and corrosive fluid handling.
2.Product Advantages
-
Outstanding resistance to seawater, brackish water, and brine corrosion.
-
Natural biofouling protection – copper ions inhibit marine organism attachment.
-
High resistance to erosion‑corrosion and impingement attack.
-
Excellent weldability, formability, and thermal conductivity.
-
Exceptional longevity – proven service life over 50 years in marine systems.
-
Immune to chloride stress‑corrosion cracking (SCC).
-
Lower weight than steel for equivalent pressure ratings.
-
More economical than titanium or high‑nickel alloys.
3.Product Applications
-
Shipbuilding & offshore – seawater cooling, ballast, fire‑fighting, and sanitary piping.
-
Oil & gas platforms – topside process lines, subsea umbilicals, and riser cladding.
-
Desalination – evaporator tubes and brine heaters.
-
Power generation – condenser tubes and cooling water circuits.
-
Industrial heat exchangers – chemical, petrochemical, and food processing.
-
Marine renewable energy – tidal/wave generator cooling systems.
-
Aquaculture – seawater supply and fish cage structures.
-
Automotive & aerospace – brake lines, power steering tubes, and aircraft ducting.
4.Key Product Parameters
| Parameter | 90/10 (C70600) | 70/30 (C71500) |
| Composition (wt%) | Cu ≥88.6, Ni 10, Fe 1.4, Mn 0.8 | Cu ~70, Ni ~30, Fe 0.6, Mn 0.5 |
| Tensile Strength (MPa) | 303 – 414 | 350 (typical) |
| Yield Strength Rp0.2 (MPa) | 110 – 393 (temper dependent) | 120 (typical) |
| Elongation (%) | 42 | 35 |
| Elastic Modulus (GPa) | 140 | 140 |
| Thermal Conductivity (W/m·K) | 50 | 29 |
| Density (g/cm³) | 8.90 | 8.95 |
| Melting Range (°C) | 1080 – 1120 | 1170 – 1240 |
| OD Range – Seamless (mm) | 6 – 159 | 6 – 159 |
| OD Range – Welded (mm) | up to 419 | up to 419 |
| Wall Thickness – Seamless (mm) | 0.5 – 8.0 | 0.5 – 8.0 |
| Wall Thickness – Welded (mm) | up to 10.0 | up to 10.0 |
| Standard Lengths | 6 m, 12 m, or custom | 6 m, 12 m, or custom |
FAQ
1. Are you trading company or manufacturer ? We are manufacturer ,You can see the certification.
2. How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. 3. Do you provide samples ? is it free or extra ? Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ? Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
