70/30 Cu-Ni Equal Tee Corrosion Resistant ASME B16.9 Buttweld Fitting for HVAC
| Place of Origin | Shanghai,China |
|---|---|
| Brand Name | TOBO |
| Certification | ISO/TUV/SGS |
| Model Number | Copper Nickel Equal Tee |
| Minimum Order Quantity | 1PC |
| Price | Negotiable |
| Packaging Details | Standard Shipping Package |
| Delivery Time | 15-30 Workdays |
| Payment Terms | T/T, Western Union |
| Supply Ability | 10Ton/Month |
Product Details
| Product Name | 70/30 Cu-Ni Equal Tee Corrosion Resistant ASME B16.9 Buttweld Fitting For HVAC | Wall Thickness | SCH10-SCH160 |
|---|---|---|---|
| Composition | Typically 90/10 Or 70/30 Copper Nickel | Packaging Type | Carton Box |
| Application | Marine, Offshore, Chemical Processing | Type | Equal Tee |
| Pressurerating | Up To 1500 Psi | Thickness | Standard |
| Package | Wooden Case | Coating | Brass |
| Productname | Copper Nickel Equal Tee | Alloycomposition | Cu-Ni 70/30 Or 90/10 |
| Temperaturerange | -29°C To 400°C | Sizerange | 1/2 Inch To 24 Inches |
| Product | Cooper Nickel Tee Equal Tee | Temperature | High Temperature |
| Highlight | 70/30 Cu-Ni equal tee,corrosion resistant buttweld fitting,HVAC copper nickel tee |
||
Product Description
70/30 Cu-Ni Equal Tee Corrosion Resistant ASME B16.9 Buttweld Fitting for HVAC
1. Product Description
The Copper Nickel Equal Tee is a high-corrosion-resistance pipe branch fitting precision-manufactured from copper-nickel alloy (Cu-Ni 90/10 or 70/30). All three ports have identical inside diameters, allowing a perpendicular branch to be created from the main pipeline for equal flow splitting or merging. The product complies with international standards such as ASME B16.9, ASTM B466/B467, and DIN 86086, and is available in seamless, welded, and fabricated forms. With excellent seawater corrosion resistance and anti-biofouling properties, it is widely used in demanding industrial fields such as shipbuilding, marine engineering, and desalination.
2. Product Applications
-
Shipbuilding:Seawater cooling, ballast, firewater, bilge systems
-
Offshore platforms:Seawater lift, process cooling, firewater ring mains
-
Desalination:Intake lines, brine circulation, concentrate discharge
-
Chemical/Petrochemical:Chloride/weak acid media, heat exchanger cooling water
-
Power (nuclear/thermal):Auxiliary cooling, condenser circulating water
-
Others:Coastal fire sprinklers, HVAC chilled water, aquarium circulation
3.Product Advantages
-
Excellent seawater corrosion resistance – 3~5× lifespan of carbon steel, resists pitting & SCC
-
Anti-biofouling – Copper ion release inhibits barnacles/algae, reduces maintenance
-
Good mechanical properties – High strength, good ductility, low-temperature toughness
-
Good weldability – GTAW/GMAW, no preheat or PWHT required
-
Erosion-corrosion resistance – Stable at seawater velocity ≤3 m/s
-
Low life-cycle cost – Long life, less replacement, lower total cost than carbon steel & some stainless
-
Full range & custom – 1/2″~48″, custom non-standard sizes, multiple connection types
4.Key Technical Parameters
| Parameter | Value |
| Material Grade | Cu-Ni 90/10 (UNS C70600), Cu-Ni 70/30 (UNS C71500) |
| Product Type | Equal Tee |
| Nominal Size | DN15 ~ DN1200 (1/2″ ~ 48″) |
| Wall Thickness Schedule | Sch10s, Sch40s, Sch80s, Sch160, XS, XXS |
| Manufacturing Standards | ASTM B122/B171/B466/B467; ASME B16.9/B16.28; MSS-SP-43; DIN 86086; EEMUA 146; EN 10253 |
| Connection Type | Butt Weld (BW) / Socket Weld (SW) / Threaded (THD) |
| Pressure Rating | Class 150 / 300 / 600; Max. 3000 psi |
| Operating Temperature | -50℃ to +300℃ |
| Chemical Composition (C70600) | Cu balance; Ni 9.0~11.0%; Fe 1.0~1.8%; Mn ≤1.0%; Zn ≤1.0% |
| Mechanical Properties | Tensile ≥275 MPa; Yield ≥105 MPa; Elongation ≥30%; Hardness HRB 52~78 |
FAQ
1. Are you trading company or manufacturer ? We are manufacturer ,You can see the certification.
2. How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ? Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ? Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
