CuNi 70/30 Heat Exchanger Tube ASTM B466 C71500 Seamless Copper Nickel Pipe
| Place of Origin | Shanghai,China |
|---|---|
| Brand Name | TOBO |
| Certification | ISO/TUV/SGS |
| Model Number | Copper Nickel Pipe |
| Minimum Order Quantity | 1PC |
| Price | Negotiable |
| Packaging Details | Standard Shipping Package |
| Delivery Time | 15-30 Workdays |
| Payment Terms | T/T, Western Union |
| Supply Ability | 10Ton/Month |
Product Details
| Product Name | CuNi 70/30 Heat Exchanger Tube ASTM B466 C71500 Seamless Copper Nickel Pipe | Thermalconductivity | Approximately 29 W/m·K |
|---|---|---|---|
| Temperaturerange | -200°C To 400°C | Alloy Or Not | Non-alloy |
| Wall Thickness | SCH40 | Package | Wooden Cases Or Pallets |
| Outer Diameter | DN10~DN900 | Surface Treatment | Polished |
| Technics | Casting | Type | Seamless Pipe |
| Diameterrange | Typically 1/2 Inch To 24 Inches | Section Shape | Round |
| Temperature Rating | 400°F | Pressure | 300/600/900 |
| Specification | Customers' Requirement | Outside Diameter | 3mm-400mm |
| Highlight | CuNi 70/30 seamless copper nickel pipe,ASTM B466 copper nickel heat exchanger tube,C71500 copper nickel pipe with warranty |
||
Product Description
CuNi 70/30 Heat Exchanger Tube ASTM B466 C71500 Seamless Copper Nickel Pipe
1.Product Description
Copper-nickel pipe is a wrought alloy tube made from a solid solution of copper and nickel, often with controlled additions of iron and manganese. It is manufactured by either seamless extrusion or longitudinal welding from strip coils. Known for its distinctive reddish-silver appearance, this pipe offers a unique combination of high ductility, excellent thermal conductivity, and outstanding resistance to impingement corrosion in turbulent or high-velocity water.
2.Product Functions
-
Shipbuilding: Main seawater intake lines, sanitary drains, and bilge and ballast systems.
-
Desalination plants: Evaporator tubing and brine heater pipes.
-
Offshore platforms: Fire main ring lines and hydraulic control lines.
-
Industrial refrigeration: Condenser and evaporator coils in ammonia systems (dried ammonia only).
-
Aerospace: Fuel and hydraulic fluid lines for aircraft (limited use).
3.Product Advantages
-
Superior erosion-corrosion resistance – Handles water velocities up to 4.5 m/s (15 ft/s) without damage.
-
Excellent weldability – No preheating needed; maintains nearly full strength after welding.
-
Low magnetic permeability – Suitable for use near compasses or sensitive electronic equipment.
-
Good resistance to hydrogen embrittlement – Safe for applications involving wet hydrogen sulfide.
-
Recyclable and eco-friendly – 100% recyclable with no loss of properties.
4.Key Product Parameters
| Parameter | 90/10 Cu-Ni (C70600) | 70/30 Cu-Ni (C71500) |
| Nominal Composition | Cu=90%, Ni=10%, Fe=1-1.8%, Mn≤1% | Cu=70%, Ni=30%, Fe=0.4-1%, Mn≤1% |
| Outside Diameter Range | 1/8″ to 12″ (3.2 mm – 323.9 mm) | 1/4″ to 10″ (6.4 mm – 273 mm) |
| Wall Thickness Schedule | Schedule 40, 80, 120, 160 & custom | Schedule 40, 80, 160 & custom |
| Standard Lengths | 20 ft (6.1 m) or random 16-20 ft | 6 m or 12 m (±10 mm) |
| Hardness (HRB) | 55 – 70 (annealed) | 70 – 85 (annealed) |
| Electrical Resistivity | 0.19 ohm-mm²/m | 0.33 ohm-mm²/m |
| Modulus of Elasticity | 140 GPa (20,300 ksi) | 150 GPa (21,750 ksi) |
FAQ
1. Are you trading company or manufacturer ? We are manufacturer ,You can see the certification.
2. How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ? Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ? Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
