C70600 CuNi 70/30 Pipe Copper Nickel Seamless Tube ASME SB111
| Place of Origin | Shanghai,China |
|---|---|
| Brand Name | TOBO |
| Certification | ISO/TUV/SGS |
| Model Number | Copper Nickel Pipe |
| Minimum Order Quantity | 1PC |
| Price | Negotiable |
| Packaging Details | Standard Shipping Package |
| Delivery Time | 15-30 Workdays |
| Payment Terms | T/T, Western Union |
| Supply Ability | 10Ton/Month |
Product Details
| Product Name | C70600 CuNi 70/30 Pipe Copper Nickel Seamless Tube ASME SB111 | Specification | Any Size Can Be Customised |
|---|---|---|---|
| Color | Copper Color | Connection | Welding |
| Price Term | CIF CFR FOB Ex-Work, CIF, CFR, FOB, CNF | Alloy Or Not | Non-Alloy |
| Outer Diameter | DN10~DN900 | Package | Wooden Cases Or Pallets |
| Packing | Pallet, Wooden Case | Pressurerating | Up To 20 MPa Depending On Specification |
| Type | Seamless Pipe / Welded Pipe | Surface | Smooth |
| Outside Diameter | 2-914mm | Surface Treatment | Polished |
| Productname | Copper Nickel Pipe | Dia | 3mm-800mm/custom |
| Delivery | According To Quantity | Wall Thickness | Varies According To Standard (e.g., SCH10, SCH40, SCH80) |
| Welding Line Type | Seamless & Welded | Tensile Strength | 40 Ksi - 60 Ksi |
| Pressure | 300/600/900 | Joining Methods | Brazing, Welding, Flanging |
| Density | Approximately 8.9 G/cm³ | Corrosion Resistance | High Resistance To Seawater And Corrosion |
| Highlight | C70600 CuNi 70/30 seamless pipe,copper nickel tube ASME SB111,CuNi 70/30 pipe with warranty |
||
Product Description
C70600 CuNi 70/30 Pipe Copper Nickel Seamless Tube ASME SB111
1.Product Description
Copper-nickel pipe is a high-performance alloy tube primarily composed of copper with nickel as the main alloying element (typically 10% or 30% nickel). It also contains iron and manganese to enhance corrosion resistance and mechanical strength. Known for its excellent resistance to seawater biofouling and erosion, this pipe is the standard material for marine and offshore applications.
2.Product Functions
-
Fluid Transport: Conveys seawater, freshwater, oil, and non-oxidizing acids.
-
Heat Exchange: Efficiently transfers heat in condensers and coolers.
-
Pressure Management: Withstands moderate to high pressure (up to 5000 psi depending on schedule).
-
Action: Copper content naturally inhibits microbial growth inside the pipe.
3.Product Advantages
-
Superior Seawater Resistance: Exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking.
-
Biofouling Resistance: Naturally prevents marine organism growth, reducing maintenance.
-
Excellent Fabricability: Can be easily bent, flanged, and welded (TIG/MIG).
-
Thermal Conductivity: Better heat transfer than stainless steel.
-
Long Service Life: Up to 40+ years in aggressive marine environments.
4.Key Product Parameters
| Parameter | C70600 (CuNi10Fe1Mn) | C71500 (CuNi30Fe1Mn) |
| Standards | ASTM B466, ASME SB466, ASTM B151 | ASTM B466, ASME SB466, ASTM B151 |
| Size Range (OD) | 6 mm – 610 mm | 6 mm – 610 mm |
| Wall Thickness | 0.5 mm – 20 mm | 0.5 mm – 20 mm |
| Length | Random (3–6 m), Fixed, or Coiled | Random (3–6 m), Fixed, or Coiled |
| Tensile Strength (min) | ≥ 290 MPa | ≥ 370 MPa |
| Yield Strength (min) | ≥ 105 MPa | ≥ 150 MPa |
| Elongation (min) | 30% | 30% |
| Max Operating Temperature | 650°C (1200°F) | 650°C (1200°F) |
| Density | 8.94 g/cm³ | 8.94 g/cm³ |
| Melting Point | 1100–1150°C | 1170–1240°C |
FAQ
1. Are you trading company or manufacturer ?
We are manufacturer ,You can see the certification.
2. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment ?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
