CuNi 70/30 Forged Flange Class 150, ASME B16.5 SWRF Corrosion-Resistant
| Place of Origin | Shanghai,China |
|---|---|
| Brand Name | TOBO |
| Certification | ISO/TUV/SGS |
| Model Number | Copper Nickel Flange |
| Minimum Order Quantity | 1PC |
| Price | Negotiable |
| Packaging Details | Standard Shipping Package |
| Delivery Time | 15-30 Workdays |
| Payment Terms | T/T, Western Union |
| Supply Ability | 10Ton/Month |
Product Details
| Product Name | CuNi 70/30 Forged Flange Class 150, ASME B16.5 SWRF Corrosion-Resistant | Surfacefinish | Smooth, Polished Or As Per Customer Specification |
|---|---|---|---|
| Density | 8.9 G/cm³ | Connection Type | Weld, Thread, Socket Weld |
| Shape | Elbow | Press | 20Bar |
| Length | 75 MM | Temperaturerange | -200°C To 400°C (varies By Alloy Grade) |
| Grade | 90/10 Copper Nickle (UNS 70600) | Application | Pipe Lines Connect |
| Weldability | Good | Thread Type | ASME B1.20.1(NPT) |
| Size Rane | 1/2 | Thickness | 3х2,5 Mm |
| Face Type | Raised Face, Flat Face, Ring Type Joint | Price Term | CIF CFR FOB Ex-Work |
| Package | Wooden Case, Pallet, Etc. | Corrosionresistance | High Resistance To Seawater And Marine Corrosion |
| Coppercontent | 70% Copper | Technics | Casting |
| Keyword | Copper Flange | Advantage | Convenient Installation And Maintenance |
| Standards | ASTM B151, ASME B16.5 | Special Functions | Resistance To Corrosion |
| Highlight | CuNi 70/30 forged flange,ASME B16.5 SWRF flange,corrosion-resistant copper nickel flange |
||
Product Description
CuNi 70/30 Forged Flange Class 150, ASME B16.5 SWRF Corrosion-Resistant
1.Product Description
This product is a high-performance Copper Nickel Socket Weld Flange manufactured from CuNi 70/30 (UNS C71500) alloy, fully compliant with ASME B16.5 standard and rated Class 150. The socket weld (SW) connection involves inserting the pipe into a recessed bore of the flange followed by a fillet weld around the pipe's outer diameter. This design ensures a smooth bore and strong, permanent joint, making it especially suitable for high-pressure and high-integrity piping systems. The CuNi 70/30 alloy provides superior resistance to seawater and biofouling.
2. Applications
The CuNi 70/30 flange is essential in environments demanding high corrosion resistance and biofouling protection. Primary applications include:
-
Shipbuilding & Marine Repairs: Seawater cooling systems, firefighting lines, ballast and sanitary systems.
-
Offshore & Coastal Infrastructure: Desalination plants (multi-stage flash and reverse osmosis), offshore platforms, and tidal energy systems.
-
Power Industry: Cooling water circuits in fossil fuel and nuclear power stations.
-
Industrial Heat Transfer: Heat exchangers, condensers, and evaporator tubing.
-
Defense & Naval: Submarine pipework and surface vessel systems (compliant with DEF STAN 02-879).
3. Product Functions
-
Secure Pipe Joining: Creates a permanent, leak‑tight fillet‑welded connection that withstands high pressure and vibration.
-
System Assembly & Disassembly: Allows piping systems to be assembled and later dismantled for inspection, repair, or modification.
-
Flow Management: Facilitates connections to valves, pumps, elbows, and tees to direct fluid flow.
-
Pressure Isolation: When combined with a blind flange, it can isolate specific sections of a pipeline for maintenance.
-
Load Transfer: Transfers mechanical loads (tension, compression, bending) across bolted flange joints.
4.Technical Specifications
| Parameter | Value / Range |
| Material Grade | CuNi 70/30 (UNS C71500) |
| Standard | ASME B16.5 – Class 150 |
| Connection Type | Socket Weld (SW) |
| Nominal Size (NPS) | 1/2″ to 24″ (DN15 to DN600) |
| Flange Face | Raised Face (RF) / Flat Face (FF) |
| Cu Content | 65.0% – 70.0% |
| Ni Content (incl. Co) | 29.0% – 33.0% |
| Fe Content | 0.40% – 1.0% |
| Mn Content | ≤ 1.0% |
| Tensile Strength (min) | 450 MPa (65 ksi) |
| Yield Strength 0.2% (min) | 170 MPa (25 ksi) |
| Elongation (min) | 30% |
| Hardness (max) | 85 HRB |
| Density | 8.94 g/cm³ |
| Melting Range | 1170 – 1240 °C |
