Seamless Copper Tube C70600 C71500 C12200 Alloy Copper Nickel Tube
| Place of Origin | China |
|---|---|
| Brand Name | TOBO |
| Certification | API/ SGS |
| Model Number | 90/10 |
| Minimum Order Quantity | 10ton |
| Price | Negotiable according to quantity |
| Packaging Details | Standard seaworthy export package or as required |
| Delivery Time | 7-45 workdays |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 300000 tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Air Condition Or Refrigerator,Oil Cooler Pipe,Water Tube,heat Exchanger,air-conditioner Ect. | Type | Coil |
|---|---|---|---|
| Length | Required | Shape | Square/Round |
| Price Term | CIF CFR FOB Ex-Work | Package | Standard Seaworthy Export Package Or As Required |
| Wall Thickness | Customized | Specification | Customized |
| Surface | Bright,polished | Product Name | Copper Nickel Plate Nickel Monel 400 ASTM B164 B127 B906 Nickel Copper Alloy Sheet And Plate Hot Rolled |
| Highlight | Seamless Copper Tube C70600,Seamless Copper Nickel Alloy Pipe |
||
Product Description
Products Specification
Copper Pipes Seamless Copper Tube TUBE C70600 C71500 C12200 Alloy Copper Nickel Tube
The Copper Nickel Sheet is also used in hydraulic tubing and brake tubing. The Cupronickel Sheet can be found in important equipment like seawater cooling, firewater systems, etc. As they show good performance at a high temperature and pressure, the Copper Nickel Alloy Sheet is also an eminent part of heat exchangers and condensers. They can also be found in the cast seawater pumps and various valve components.
The hardness of Cupro Nickel Plate is lesser than the stainless steel plates, which means they are much more flexible. One can easily create forms and flares with Cupro Nickel Sheet for repairing, and unlike stainless steel, these are easy to work with. As the Cupro Nickel Sheet can be bent and flared easily, hence they are capable of creating a tighter seal.
There are several features of Copper Nickel Sheets which make them ideal for several applications and hence popular among different industries.
- They are highly resistant to seawater corrosion and biofouling.
- They can resist chlorides in terms of pitting, stress corrosion cracking and crevice corrosion, even at a higher temperature.
- They possess good thermal conductivity.
- They are highly ductile.
- They are able to maintain their performances at higher temperatures.
- They have antimicrobial properties and hence can be used for healthcare applications.
- The Copper Nickel Strip can be customized according to the requirements given by the clients.
- Their shape, size, dimensions, andsurface finishes are made according to the application needs.
USED:
1)Further making utensil.
2)Solar reflective film
3)The appearance of the building
4)Interior decorating:ceilings,walls,etc.
5)Furniture cabinets
6)Elevator decoraction
7)Signs,nameplate,bags making.
8)Decorated inside and outside the car
9)Household appliances:refrigerators,microwave ovens,audio equipment,etc.
10)The consumer electronics:mobile phones,digital cameras,MP3,U disk,etc.
Copper Nickel Plate specifications
| Manufacturing Standard | Cuni Plate : ASTM B122, MILITARY MIL-C-15726 |
| Cu-Ni Clad Plate: ASTM B432 | |
| Copper Nickel Strips: ASTM B122, MILITARY MIL-C-15726 | |
| International Standards | JISH3100-2006, ASTMB75M-02, JISH3250-2006, GB/T1527-2006, JISH3300-2006, ASTMB152M-06, ASTMB187, ASTMB42-02, GB/T5231-2001 etc. |
| Specifications | Thickness: 0.1mm~200mm |
| Width: 10mm~2500mm | |
| Sizes in stock | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Length | 10mm~12000mm, or as required. |
| Surface | Mill, polished, bright, oiled, hair line, brush, mirror, sand blast, or as required. |
| Form of | Copper Nickel Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
Copper Nickel Plate Chemical Composition
| Element | C70600 | C70620 |
| Cu | Balance | min. 86.5% |
| Ni | 9.0% - 11.0% | 9.0% -11.0% |
| Fe | 1.0% - 1.8% | 1.0% - 1.8% |
| Zn | max. 1.0% | max. 0.5% |
| Pb | max. 0.05% | max. 0.02% |
| Mn | max. 1.0% | max. 1.0% |
| C | max. 0.05% | |
| P | max. 0.02% | |
| S | max. 0.02% |
Packing & Shipping
Product Show
FAQ
1.How do you let me trust you?
We are a Golden supplier in Alibaba who do business for more than 5 years. You can make an order by Alibaba to us directly.
2.How about your price?
High-quality products with a reasonable price suitable for your market.
3.How do you control your quality?
We request a QC inspection for each batch of goods. And we can provide you inspection report and mill certificate if you want..
We are a Golden supplier in Alibaba who do business for more than 5 years. You can make an order by Alibaba to us directly.
2.How about your price?
High-quality products with a reasonable price suitable for your market.
3.How do you control your quality?
We request a QC inspection for each batch of goods. And we can provide you inspection report and mill certificate if you want..
4.Could you provide free samples?
For new customers, We can provide free samples for standard fasteners. But the clients will pay the express charges. For regular customers, We will send you free samples and pay express charges by ourselves.
5.How about your delivery time?
Generally speaking, All the goods have stock with little quantity, we can delivery them with one week. If the quantity is 1-2container, we can give you with 30-45days.
7.What is your payment term?
We can accept T/T,LC for general order. For new customer, we request 20%-50% T/T in advance, and balance payment should against B/L copy. For regular customer, we can provide delay payment after B/L date about 30-90 days.
